| Model No. | TGW-WT001AD |
| Cabinet Material | 304 Stainless Steel |
| Dimensions | Cabinet:1200*300*980mm |
| Weight | 80KG |
| Motor Type | Single motor |
| Arm Length | ≤300mm |
| Passage Width | ≤600mm |
| Dry Contact | 12V |
| Material Thickness | 1.5mm |
| Card-reading Window | Two |
| Direction | Unidirectional |
| Service Life | 5million times |
| Operating Temperature | -25ºC ~ +60ºC |
| Related Humidity | ≥90%RH |
| Communication Interface | TCP/IP |
| Power Supply | AC 220V/110V ±10% 50/60MHZ (optional) |
| Opening Speed: | 30-45persons per minute |
| Closing Speed: | 25-35 persons per minute |
Q: Did your system have software interface?
A: Yes. We have our own management software.
Q: How does this system link to other system?
A: Equipment could link to others by TCP/IP.
Q:Does this combo can add extra access control method?
A: Yes,we can extend card reader,fingerprint reader and other method to connect wire with face recognition terminal.
Q: What will happened if power was cut off?
A: Once cut off,the turnstile gates arm would be drop off,it can go through without control.
